3D Design / CAM

Full Service design and engineering services for your tooling programs.

Fixtures & Gages

CNC Machining

 Low Volume Production Precision Machining and Wire EDM

In House Heat Treat

Allows for faster Lead-times on repairs and details.

Tool & Die

Full service tool & die / die try out / low volume stamping and fabrication services.
Precision Details

Made is USA and LCC. With quick turn around from both and unlimited capacity.

---

1500 TON TRY OUT PRESS / Coil Fed

---

• ​Press: Clearing

• Press Type: SS

• Capacity: 1500 ton

• Stroke: 32”

• Slide Adjustment: 28”

• Bolster Thickness: 12”

• Shut Height: 60” over bolster

• Bed Size: 144” x 96”

• Stroke per min: 9

• Electrical Controls: Allen-Bradley

• ​20,000# x 60" Cincinnati Inc. Motorized Un coiler w/ Coil Car

• Model: CPR-60-20-16-24-R-L

• Max OD: 72"

• ID Range: 18" - 22"

• Traveling Coil Car

---

Building & Equipment

3D Design / CAM Capabilities
• (2) 3D Design Workstations w/ Solidworks 2015 and Logopress3 software
• (2) Programming Workstations for CNC Wire EDM equipment w/ MasterCam r10
EDM Equipment
• Fanuc Wire EDM, Model Alpha 1iE
• Sodick Wire EDM, Model LN1W
Milling Machines
•(4) Millport #3KVII
• (2) Cincinnati #2 Vertical
Jig Bores
• Pratt & Whitney Model #388
• Cincinnati #4 Vertical
Jig Grinders
• Moore Jig Grinder #1
• Moore Jig Grinder #2

Drill Presses
•( 2) Clausing 20”
• Wilton Model #24203
Radial Drill Presses
• Ikeda 3’ arm
• American Hole Wizard 6’ arm, 17” column
• American Hole Wizard 5’ arm, 15” column
Horizontal Boring Mill
• Cincinnati Gilbert 3 ½” spindle, 42” x 66”
   Travel: 48” v, 50” c, 60” l
Lathes
• Colchester 15” x 48”
• Monarch 26” x 72”
Haas SL 30, VOP-D with live tooling. The maximum OD is 14” and length is 20”.

CNC Machining Centers
• (1) Leadwell Model #MCV-760AP
• (1) Leadwell Model #MCV-1000AP
• (1) Leadwell Model #MCV-1300P
Building
• Office space – 3,050 sq. ft.
• Manufacturing – 14,150 sq. ft.

Press Equipment

• Press Room Equipment
• Minster S.S. press, 250 ton
• Cleveland S.S. press, 200 ton
• American Steel Line 36” Model 60
• Little Feeder 18”
• Dallas 18” X 30” air feed
Grinders
• Gallmeyer-Livingston Surface 12” x 48”
• Gallmeyer-Livingston Surface 12” x 36”
•(3) Okamoto Surface 12” x 24”
•Harig Surface 6” x 18”
•(3) Harig Surface 6” x 12”
Heat Treatment
• (1) Hupert Model 2020
• (1) Knight Dragon Fire Furnace
Material Handling
• Caterpillar – 15,000# capacity
• Yale Forklift – 8,000# capacity
• Clark Forklift – 5,000# capacity
• (2) Jet chain hoists – 2 ton
• (2) Overhead cranes – 5 ton

Minster S.S. press, 250 ton

---
